DeltaTRAK manufactures products under an ISO 9000 registered quality management system

Internal Temp Sensor Range

-40°F to 150°F (-40°C to 66°C)

Temperature Accuracy

±1°F (0.5°C) at 32°F to 150°F (0°C to 66°C)
±2°F (1°C) over entire range

Temperature Resolution

0.1°F/C

Logged Data Capacity

3,822 data points

Data Download Time

5 second typical for 3,800 data points

Programmable Alarm Levels

High and Low Levels over entire range

Startup Alarm Delay

Skip 1 to 16 points

Operating Alarm Delay

0 to 79 minute delay filter

Logging Time Interval Range

3 seconds to 24 hours

Programmable Delayed Start

0 seconds to 256 days

LED Indicators

12-second flashing red for alarm; green for active

Battery Type/ Life

CR2450 3v lithium/ 1 year

Dimensions/ Enclosure

ABS plastic case, 3.25 x 2.25 x .75 in. (8.3 x 5.7 x1.9 cm.)

Water Resistance

IP56

Shock Resistance

Withstands 3-foot drop to hard surface

Certification

CE Mark by T.U.V.; Calibration Traceable to N.I.S.T.

Min. System Requirements

IBM compatible 486 with 4MB RAM, WIN3.1, ‘95, ‘98, 2000, or NT

Software Requirements

FlashLink Program Manager Software
