DeltaTRAK manufactures products under an ISO 9000 registered quality management system

Field of View

D:S=15:1 At D=1 meter(39.4”); S=66.7mm(2.6”) minumum spot size = 12.7mm (0.5 in.)

Temperature Range

-22°F to 392°F (-30°C to 200°C)

Display Range

-40°F to 428°F (-40°C to 220°C) *Extreme temperatures within the display range cannot be verified for accuracy

Environmental Operating Range

14°F to 122°F (-10°C to 50°C)

Response Time

Less than 1 second

Accuracy

±1°F at 75.2°F (±0.5°C at 24°C) ±1.8°F from 32°F to 212°F (±1°C from 0°C to 100°C) otherwise ±3.6°F (±2°C)

Environmental Humidity Range

0% to 95% RH (without dew condensation)

Display Hold Time

15 seconds

Scale

°F/ °C selectable

Repeatability

±2°F (1°C) of reading value

Body Casing

ABS plastic

Battery

9v alkaline (12 hour life)

Emissivity

Dark (.95)/Bright (.85) switchable

Display Resolution

0.1°F (0.1°C)

Sighting Method

Offset laser 630nm to 670nm

Weight

7.05oz. (200g) including battery

Size

6.3 in. (L) x 1.7 in. (W) x 1.65 in. (D) (15cm x 4cm x 4 cm)

Caution

Laser radiation: do not stare into beam, Class 2 Laser Product
