DeltaTRAK manufactures products under an ISO 9000 registered quality management system

Temperature Measurement Range

-112°F to 14°F (-80°C to -10°C)

Temperature Accuracy

±1.0°F (±0.5°C) from -22°F to -112°F or -30°C to -80°C
±2.7°F (±1.5°C) from 14°F to -22°F or -10°C to -30°C

Temperature Resolution

0.1°F/°C

Battery Type / Life

AA (1/2) 3.6Vdc Lithium/6 to 10 years in live mode)

Compliance

CE Mark, N.I.S.T. traceable and FCC part 15

Enclosure (Casing)

High impact Acrylonitrile Butadiene Styrene (ABS) plastic

Frequency Control

FM (Frequency Modulation)

Frequency Range

418 MHz or 902 - 928MHz , unlicensed ISM Band

Unique Identifier

22-character unique ID

Network Topology

Point-to-point transparent networking

Operating Temperature

-40°F to 185°F (-40°C to 85°C)

Probe (Material / Length)

Teflon sleeve covered sensor/4ft or 1.2m

Tx (Transmission) Range

600ft (183m) Line-of-Sight

Size

3.063in (L) 1.938in (W) 0.875in (H) (79 x 50 x 22 mm)

Weight

1.5 oz.

Transmitter Type / Timing

Frequency hopping spread spectrum/15 milliseconds transmission time at random intervals

Transmission / Logging Intervals

10 to 17 seconds random/Transmit reading every 1 min.

Transport Protocol

Various monitoring and addressing modes

Revision 06I1
